Pompes de transfert de carburant à courant continu
Pompes à palettes électriques rotatives auto-amorçantes à déplacement pour le transfert de carburant diesel équipées d'une vanne de dérivation.
Yoilp1229M-C 12V
• FUEL TRANSFER PUMP • Voltage: DC12V,DC24V • Rated Input Power:600W • Max pump rate: 50L/min • Pressures: 3Bar • Speed: 3000RPM • Inlet/Oulet:BSPT/NPT1" • Use for Gasoline,diesel,kerosene
- 技术参数
- 详细描述
-
- Nom d'article: Pompes de transfert de carburant à courant continu
- Numéro d'article: D-A011
- 产品型号: Yoilp1229M-C 12V
- 参数: • FUEL TRANSFER PUMP • Voltage: DC12V,DC24V • Rated Input Power:600W • Max pump rate: 50L/min • Pressures: 3Bar • Speed: 3000RPM • Inlet/Oulet:BSPT/NPT1" • Use for Gasoline,diesel,kerosene
Pompes à palettes électriques rotatives auto-amorçantes à déplacement pour le transfert de carburant diesel équipées d'une vanne de dérivation.
DC fuel transfer pumps
Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
Technical specifications
• Cast iron pump body finished with anti-corrosion paint.
• Vane pump with sintered steel rotor and acetal resin vanes.
• By-pass valve incorporated in the pump body.
• Direct current brush motor with permanent magnet stator.
• Motor protection grade IP55.
• Used in intermittent service with 30-minute work cycles.
DC fuel transfer pumps
Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
Technical specifications
• Cast iron pump body finished with anti-corrosion paint.
• Vane pump with sintered steel rotor and acetal resin vanes.
• By-pass valve incorporated in the pump body.
• Direct current brush motor with permanent magnet stator.
• Motor protection grade IP55.
• Used in intermittent service with 30-minute work cycles.
Keywords:
en relation
DC PUMPS
1225C 12V
• 50L/MIN • 260W • 2600RPM • 3/4" • 22A(12V),11A(24V) • 1.5BAR • 3.5KGS • 4/CTN 19/18KGS 36X23X32CM
DC PUMPS
1225B 12V
• 50L/MIN, 13GPM • 260W • 2600RPM • 1" • 24A(12V),17A(24V) • 1.5BAR • 3.5KGS • 4/CTN 19/18KGS 36X23X32CM
DC PUMPS
1225A 12V
• 50L/MIN, 13GPM • 260W • 2600RPM • 1" • 22A(12V),17A(24V) • 1.5BAR • 3.5KGS • 4/CTN 19/18KGS 36X23X32CM
