Débitmètre à déplacement positif série M
YPUMP-TCS-40
| Model | YPUMP-TCS-40 | YPUMP-TCS-50 | YPUMP-TCS-80 | YPUMP-TCS-100 |
| Size | 40mm/1.5 ” | 50mm / 2" | 80mm / 3 ” | 100mm/4" |
| Flow Range | 25-250L/min | 50-500L/min | 100-1000L/min | 130-1300L/min |
|
Max. Pressure |
10Bar/150PSI |
|||
|
Accuracy |
±0.2% |
|||
|
Repeatability |
≤0.05% |
|||
|
Standard Measurement |
Unit Liter / US Gallon | |||
|
Meter Body |
Aluminum, Cast Iron, Stainless Steel available |
|||
|
Seal & Gasket |
Buna"N"; Viton; Teflon available |
|||
|
Stranier Mesh |
80 for Diesel, 40 for Gasoline |
|||
|
End Connections |
ANSI Flanged, NPT, BSPT, Slip Weld available |
|||
|
Viscosity |
30SSU~1,500,000SSU |
|||
| Pakeage | 51 x46x49cm | 51 x46x49cm | 58x 50x61 cm | 76x64x72cm |
| 25/23kgs | 28/26kgs | 47/40kgs | 93/70kgs | |
| 1PC/CTN | 1PC/CTN | 1PC/CTN | 1PC/WOODEN CASE | |
- 技术参数
- 详细描述
-
- Nom d'article: Débitmètre à déplacement positif série M
- Numéro d'article: K-A004
- 产品型号: YPUMP-TCS-40
- 参数:
M Series Positive Displacement Flow Meter
Advantage:
• Excellent stepless adjusting mechanism allows a micro adjustment of the meter
• High accuracy and repeatability over the widest range of flow;
• Superior accuracy at constant flow
• Low maintenance, no metal-to-metal contact in measuring chamber, long life service
• Low pressure loss, a true gravity flow meter
• Accuracy regardless of pressure fluctuations, temperature variation, viscosity
• Choice of aluminum, cast iron and stainless steel materials of construction.Application
Application includes: batching, dispensing, inventory control and custody transfer of oils, solvents, chemicals, paints, fats and fertilizer.
-
Model YPUMP-TCS-40 YPUMP-TCS-50 YPUMP-TCS-80 YPUMP-TCS-100 Size 40mm/1.5 ” 50mm / 2" 80mm / 3 ” 100mm/4" Flow Range 25-250L/min 50-500L/min 100-1000L/min 130-1300L/min Max. Pressure
10Bar/150PSI
Accuracy
±0.2%
Repeatability
≤0.05%
Standard Measurement
Unit Liter / US Gallon Meter Body
Aluminum, Cast Iron, Stainless Steel available
Seal & Gasket
Buna"N"; Viton; Teflon available
Stranier Mesh
80 for Diesel, 40 for Gasoline
End Connections
ANSI Flanged, NPT, BSPT, Slip Weld available
Viscosity
30SSU~1,500,000SSU
Pakeage 51 x46x49cm 51 x46x49cm 58x 50x61 cm 76x64x72cm 25/23kgs 28/26kgs 47/40kgs 93/70kgs 1PC/CTN 1PC/CTN 1PC/CTN 1PC/WOODEN CASE
M Series Positive Displacement Flow Meter
Advantage:
• Excellent stepless adjusting mechanism allows a micro adjustment of the meter
• High accuracy and repeatability over the widest range of flow;
• Superior accuracy at constant flow
• Low maintenance, no metal-to-metal contact in measuring chamber, long life service
• Low pressure loss, a true gravity flow meter
• Accuracy regardless of pressure fluctuations, temperature variation, viscosity
• Choice of aluminum, cast iron and stainless steel materials of construction.
Application
Application includes: batching, dispensing, inventory control and custody transfer of oils, solvents, chemicals, paints, fats and fertilizer.
